Jobber Drills – Viper Plus

D184

Drills bits with EXTRA bite. Viper Plus is an industrial quality drill bit designed for machine and hand held drilling in stainless steel, steel, aluminium, cast iron, brass, wood and plastic. Featuring a Futura Nano PVD coated tip – the latest generation coating for ultimate wear resistance and increased productivity. This drill bit has been independently tested to exceed 2X tool life compared to standard Viper drill bits.

Download PDF

Range

Features

Application

Specification

Resources

Item #

Diameter d1 (mm)

Length l1 (mm)

Length l2 (mm)

RRP
(inc GST)

Info

D1840100

1.00

$5.50

D1840150

1.50

$5.75

D1840200

2.00

$6.50

D1840250

2.50

$6.50

D1840300

3.00

$6.75

D1840330

3.30

$6.95

D1840350

3.50

$6.95

D1840400

4.00

$7.25

D1840420

4.20

$8.25

D1840450

4.50

$8.25

D1840500

5.00

$9.25

D1840550

5.50

$9.95

D1840600

6.00

$10.50

D1840650

6.50

101

$11.50

D1840680

6.80

109

$13.50

D1840700

7.00

109

$13.95

D1840750

7.50

109

$15.50

D1840800

8.00

117

$16.95

D1840850

8.50

117

$17.95

D1840900

9.00

125

$20.95

D1840950

9.50

125

$23.95

D1841000

10.00

133

$25.95

D1841020

10.20

133

$27.95

D1841050

10.50

133

$28.95

D1841100

11.00

142

$33.95

D1841150

11.50

142

$37.95

D1841200

12.00

151

101

$40.95

D1841250

12.50

151

101

$41.95

D1841300

13.00

151

101

$44.95

Independently tested to exceed 2X greater tool life
Futura Nano PVD coated tip for ultimate wear resistance
Specialised coating allows higher cutting speeds and greater productivity
Made from M2 High Speed Steel (HSS) offering the best combination of strength, heat & wear resistance
118° split point tip minimises wandering when starting

ISO	VDI	Description	Condition	Hardness	Strength
P	1	Steel - Non-alloy, cast & free cutting (~ 0.15 %C)	Annealed	125MPa	440MPa
P	2	Steel - Non-alloy, cast & free cutting (~ 0.45 %C)	Annealed	190MPa	640MPa
P	3	Steel - Non-alloy, cast & free cutting (~ 0.45 %C)	Quenched & Tempered	250MPa	840MPa
P	4	Steel - Non-alloy, cast & free cutting (~ 0.75 %C)	Annealed	270MPa	910MPa
P	5	Steel - Non-alloy, cast & free cutting (~ 0.75 %C)	Quenched & Tempered	300MPa	1010MPa
P	6	Steel - Low alloy & cast < 5% of alloying elements	Annealed	180MPa	610MPa
P	7	Steel - Low alloy & cast < 5% of alloying elements	Quenched & Tempered	275MPa	930MPa
P	8	Steel - Low alloy & cast < 5% of alloying elements	Quenched & Tempered	300MPa	1010MPa
P	9	Steel - Low alloy & cast < 5% of alloying elements	Quenched & Tempered	350MPa	1180MPa
P	10	Steel - High alloy, cast & tool	Annealed	200MPa	680MPa
P	11	Steel - High alloy, cast & tool	Hardened & Tempered	325MPa	1100MPa
P	12	Steel - Corrosion resistant & cast - Ferritic / Martensitic	Annealed	200MPa	680MPa
P	13	Steel - Corrosion resistant & cast - Martensitic	Quenched & Tempered	240MPa	810MPa
M	14.1	Stainless Steel - Austenitic	Age Hardened	180MPa	610MPa
M	14.2	Stainless Steel - Duplex		250MPa	840MPa
M	14.3	Stainless Steel - Precipitation Hardening		250MPa	840MPa
K	15	Cast Iron, Grey (GG) - Ferritic / Pearlitic		180MPa	610MPa
K	16	Cast Iron, Grey (GG) - Pearlitic		260MPa	880MPa
K	17	Cast Iron, Nodular (GGG) - Ferritic		160MPa	570MPa
K	18	Cast Iron, Nodular (GGG) - Pearlitic		250MPa	840MPa
K	19	Cast Iron, Malleable - Ferritic		130MPa	460MPa
K	20	Cast Iron, Malleable - Pearlitic		230MPa	780MPa
N	21	Aluminum & Magnesium, wrought alloy - Non Heat Treatable		60HB	210MPa
N	22	Aluminum & Magnesium, wrought alloy - Heat Treatable	Age Hardened	100HB	360MPa
N	23	Aluminum & Magnesium, cast alloy ?12% Si - Non Heat Treatable		75MPa	270MPa
N	24	Aluminum & Magnesium, cast alloy ?12% Si - Heat Treatable	Age Hardened	90MPa	320MPa
N	25	Aluminum & Magnesium, cast alloy >12% Si - Non Heat Treatable		130MPa	460MPa
N	26	Copper & Copper alloys (Brass/Bronze) - Free cutting, Pb > 1%		110MPa	390MPa
N	27	Copper & Copper alloys (Brass/Bronze) - Brass (CuZn, CuSnZn)		90MPa	320MPa
N	28	Copper & Copper alloys (Brass/Bronze) - Bronze (CuSn)		100MPa	360MPa
N	29	Non-metallic - Thermosetting & fiber-reinforced plastics
N	30	Non-metallic - Hard rubber, wood etc.
S	31	High temperature alloys - Fe based	Annealed	200HB	680MPa
S	32	High temperature alloys - Fe based	Age Hardened	280HB	950MPa
S	33	High temperature alloys - Ni / Co based	Annealed	250HB	840MPa
S	34	High temperature alloys - Ni / Co based	Age Hardened	350HB	1180MPa
S	35	High temperature alloys - Ni / Co based	Cast	320HB	1080MPa
S	36	Titanium & Titanium alloys - CP Titanium			400MPa
S	37.1	Titanium & Titanium alloys - Alpha alloys			860MPa
S	37.2	Titanium & Titanium alloys - Alpha / Beta alloys	Annealed		960MPa
S	37.3	Titanium & Titanium alloys - Alpha / Beta alloys	Age Hardened		1170MPa
S	37.4	Titanium & Titanium alloys - Beta alloys	Annealed		830MPa
S	37.5	Titanium & Titanium alloys - Beta alloys	Age Hardened		1400MPa
H	38.1	Hardened steel	Hardened & Tempered	45HRC
H	38.2	Hardened steel	Hardened & Tempered	55HRC
H	39.1	Hardened steel	Hardened & Tempered	58HRC
H	39.2	Hardened steel	Hardened & Tempered	62HRC
H	40	Cast Iron - Chilled	Cast	400MPa	1350MPa
H	41	Cast Iron	Hardened & Tempered	55HRC

Wood

Metal

Specialty

Masonry

Soft Wood
Hard Wood
Wood & Nails
Chipboard
Plywood
MDF
Green Wood
Sandwich Construction
Pallet
Window Frame

Steel
Hard Steel
Stainless Steel
Aluminium
Copper / Brass
Cast Iron
Sheet Metal
Precious Metals
Metal Pipe

PVC Plastic
Acrylic
mineral rock wool foams (EPS, PUR), Polystyre
Leather
Rubber
Fibreglass
Carbon Fibre
Glass
Laminate

Masonry
Plasterboard
Compressed Fibre Cement
Cement Sheet
Ceramic Tile
Hebel
Brick
Concrete
Reinforced Concrete
Stone
Granite
Marble

KEY

Optimal Effective PSteel MStainless KCast Iron NNon-Ferous Metals STitanium & Super Alloys HHard Materials
